Pneumatic tyred roller series are designed for the compact cohesive and non-cohesive materials, such as asphalt concrete, cement or lime stabilized soils, gravels, sands and clay mixtures, Rolling Cement Concrete (PCC) in the construction projects, especially suitable for the preparation of the upper courses of high grade highway.
Main Features of Pneumatic tyred roller
*LTP2030、LTP1826、LTP1016 low gravitational center designed for safe and comfortable operation.
*LTP2030、LTP1826 adopt CUMMINS 6BTA diesel engine. Powerful strength is suitable to all environments.
*Three forward speed and two backward changes. Glass fiber reinforced plastic spraying box and multi-layer water
*Filter ensure the stability of the system.
*With stepless speed changes LTP2030H、LTP1826H、LTP1016H is easy and reliable to operate.
*Power strength,LTP1016、LTP1016H which adopted 4BT Cummins engine, is suitable to all environments.
*Front wheel with auto adjusting Heating structure to perform better compactness.
Main Technical Parameters of Pneumatic tyred roller
| MODEL | LTP2030 | LTP1826 | LTP1016 | LTP2030H |
| Operating mass (kg) | 20000/30000 | 18000/26000 | 10000/16000 | 20000/30000 |
| Max travel speed (km/h) | 20.75 | 20.75 | 20.75 | 0-14 |
| Type quantity (mm) | 5+6 | 5+6 | 4+5 | 5+6 |
| Min turning radius (mm) | 8000 | 8000 | 7500 | 8000 |
| The presses width (kn) | 2790 | 2790 | 2286 | 2790 |
| Grade ability ( %) | 20 | 30 | 20 | 20 |
| Overall dimension (mm) | 4800x2800x3100 | 4800x2800x3100 | 4780x2280x3200 | 4800x2790x3100 |
| Wheelbase (mm) | 3800 | 3800 | 3700 | 3800 |
| Diesel power | 125 | 125 | 75 | 125 |
| Diesel model (kw) | EQ6BTA5.9-C125 |
EQ6BTA5.9-C125 |
4BT3.9-C100 | EQ6BTA5.9-C125 |
Pneumatic roller is characterized of high working efficiency and compaction performance. By increasing or decreasing ballast and changing the pneumatic pressure in tyres., which realizes the dense compaction on the layer material without leaving any false compaction, so as to ensure the road surface hardness and shearing strength.
